The Solar Cell Base System is a comprehensive educational platform designed for learning and experimenting with solar energy and its various components. This system includes monocrystalline silicon solar cells that serve as the core component for experiments, providing valuable hands-on experience with solar energy conversion. The solar cells have specific parameters like an open-circuit voltage of 1.5V, a short-circuit current of 2.3A, and a maximum power of 1.1W per unit. These solar cells are paired with a self-contained trainer unit capable of adjusting solar irradiation and azimuth for simulating sunlight, allowing for experiments under varied conditions.
The system features a halogen lamp as a light source to simulate sunlight for the solar cells, with adjustable brightness and a beam angle of 60°. This is supported by a dimmer for regulating the light intensity, with input options for both 110VAC and 220VAC and an output of 12V. The Digital Multimeter included in the setup is essential for measuring DC and AC voltage, current, resistance, and more, offering a range of input and output resistances and providing accuracy for testing and calibration. The energy storage options include NiMH rechargeable batteries and super capacitors for storing energy generated during experiments.
A DC motor and light bulb are included as loads to demonstrate the energy output from solar cells, and the potentiometer allows for variable resistance testing. The system also features an Inverter with an output of a square wave at 2Vpp and 50/60Hz frequency, converting DC to AC.
The system is powered by an AC power supply (110/220 VAC), with a 15VDC output for testing. The DAQ (Data Acquisition System) is integrated for collecting and saving experimental data, supporting software for Windows XP, Vista, 7, and 8, and ensuring that the experiments are recorded accurately for analysis.
Additional accessories such as test leads, shading plates (25%, 50%, 75%, 100%), and a solar power meter are included for measuring irradiation and energy conversion efficiency. The Solar Power Meter offers a detailed readout, with a resolution of 0.1 W/m² and an accuracy of ±10 W/m². Experiments include measuring solar cell irradiation, energy conversion efficiency, current-voltage (I-V) curves, and simulating real-world conditions like daily sunlight variation and shading effects.
The system comes with a 5-day training package and a 2-year warranty, ensuring that users can set up, operate, and maintain the equipment effectively. This system is designed for educational use, providing valuable insights into solar energy principles, energy conversion, and the practical application of solar technologies.
Solar Cell Base :
1. Solar Cell Modules 1. 4 pcs of monocrystalline silicon solar cell 6*12 cm-10cm×18cm -Each solar cell unit: -Open circuit voltage (Voc): 1.5V -Short circuit current (Isc): 2.3A -Maximum load voltage (Vpm): 1.5V -Maximum load current (Ipm): 2.2A -Maximum power (Ppm): 1.1W
-Self-contained solar cell trainer -Adjustable solar irradiation and azimuth for sunlightsimula tion -Equipped with DAQ is advantageous to acquireand save the experimental data
2. Dimmer (1) Adjust the brightness of halogen lamp: -Input voltage 110VAC or 220VAC -Output voltage 12V -Light Source (1) Halogen lamp 12V / 50W (2) Beam angle 60°
Solar Cell Module: 1. Digital Multimeter x 2 -DC Voltage: 400mV, 4V, 40V, auto range, Inputresistance ≥ 10MΩ -AC Voltage: 400mV, 4V, 40V, auto range, Inputresistance ≥ 10MΩ -DC Current: 400μA, 400mA,10A, push buttonselector switch -10A Range: 10A/250V fuse protected, mA/μARanges: 0.5A / 250V fuse protected -AC Current: 400μA, 400mA,10A, push buttonselector switch, 10A -Range: 10A/250V fuseprotected, mA/μA Ranges: 0.5A/250V fuse protected -Resistance: 400Ω, 4K Ω, 40K Ω, 4M Ω, 40M Ω,auto range -Diode test: 0~1.5V -Continuity: Buzzer for the measured resistance <30 Ω -Display: 3 3⁄4 digit LCD, max. indication 3999
2. Energy Storage -NiMH rechargeable battery 1.2V / 80mAh -Super capacitor 10F / 2.7V
Features :
3. Load -DC motor: -Light bulb: 1.1V, 300mA -Potentiometer: 100Ω, 10-turn
4. Inverter -Input voltage: 2VDC -Output:
b. Square wave 2Vpp 50/60Hz
Power Supply: 1. Input voltage 110/220 VAC 2. Output voltage 15VDC
DAQ with Software: -Channel 1 and 2: max. input voltage ±5V -Channel 3 and 4: max. input current 1A -DAQ type: Windows XP / Vista / 7 / 8
4. System requirement -PC: 1GHz or faster 32-bit (x86) or 64-bit (x64)processor, 1GB RAM, 1GB more free disk space -OS: Windows XP / Vista / 7 / 8
List of Experiments: -Measuring the irradiation of various light sources -Energy conversion of solar cells -Diode characteristic of a solar cell
of solar cell
Accessories and Others : -Test leads: 1 set -Experiment manual -Instructor’s manual -Basic solar power meter -Operating with DAQ -Measuring range 10~1200W/m2 -5. 25% Shading plate -50% Shading plate- -75% Shading plate- -100% Shading plate -Experiment Manual -Standard accessories. -Inatsllation, Testing. -Training : 5 Days -Warranty: 02 year
current of solar cells -Relationship between the angle of irradiation and the short-circuit current of solar cell. -Open-circuit voltage and short-circuit current of solar cells connected in series-shading -Open-circuit voltage and short-circuit current of solar cells connected in parallel-shading -I-V curve of solar cells
-Simulating a daily course of sunlight – Charging a capacitor with solar cells – Capacitor discharging – Constructing a solar power island system -Inver ter
Solar Power Meter : 1. Display: 3 1⁄2 digit LCD, max indication 1999 2 2 2. Measuring range: 2000 W/m, 634 Btu/ (ft x h) 2 2 3. Resolution: 0.1 W/m, 0.1 Btu/ (ft x h) 2 2 4. Accuracy: ±10 W/m, ±3 Btu/ (ft x h) 5. Sampling rate: 2 Hz
Safety & Security: Over voltage, over current and earth fault protection.
